Microscopes > Upright microscopes > Bright field microscopes > Evident Olympus > CX43 > Evident Olympus Microscope CX43 Standard, trino, infinity, LED, w.o. objectives!
Product no.: 53991

Microscope CX43 Standard, trino, infinity, LED, w.o. objectives!

$ 3,920.00 incl. VAT plus shipping costs
too expensive?
short-term
ready for shipping in 3-5 weeks + lead time

No delivery possible before Christmas. Order a voucher coupon!


Product questions?
advice for Microscopy

Product description

More about the series CX43...

Olympus CX43 Basic equipment with trinocular tube (E07MIS0053)

Comfortable, High-Throughput Routine Microscopy

The CX43 microscope enable users to remain comfortable during long periods of routine microscopy observations. The microscope frame conforms to the user’s hands and the location of the control knobs maximize ergonomics to improve work efficiency. Users can quickly set a specimen with one hand, while adjusting the focus and operating the stage with the other hand with minimal movement. The microscope also features an optional camera port for digital imaging.

Upright microscope set for transmitted and reflected light observations with trinocular tube

  • integrated LED illumination
  • low-positioned quintuple nosepiece
  • mechanical stage (211 x 154 mm, travelling range 76 x 52 mm) with right handle, low drive control, stage lock pin and specimen holder for one slide
  • Abbe condenser, NA 1.25
  • 7 position turret: BF(4X - 100X), 2X, DF, Ph1, Ph2, Ph3, FL with shutter
  • Coaxial/fine focus, complete stroke 15 mm, fine stroke 300 µm/rotation, graduation 2.5 μm,
  • trinocular tube with two widefield eyepieces for FN20

Included components:

  1. Trinocular tube U-CTR30-2-2 (N1468300)
  2. WHB10X-H Eyepiece 10x/20 dioptric compensation (N1130000)
  3. WHB10X-2 Eyepiece 10x/20 (N1129900)
  4. CX43RF tripod incl. rotating condenser (N5731700)
  5. UYCP cable (035425)
  6. Dust cover (038159)

Without objectives!!

Please choose your objectives from the accessories!

Specifications

Optics

Number of objectives
0
Lighting
Transmitted light
Condensor
Abbe
Lamp type
LED
infinity corrected
yes
Optical system
infinity
Eyepiece
10x/20

Capacity

brightfield
yes
Phase contrast
yes
Dark field
yes

Mechanics

Type of build
Trinocular
Focusing
Coarse and fine movement
Specimen stage
Cross table (211 x 154 mm)
Revolver
5

Special features

Luminous field diaphragm
yes
Wide-angle eyepiece
yes (10x/22)

General

Width (mm)
211
Length (mm)
397
Height (mm)
393
Series
CX43
Weight (g)
7,3

Field of application

Medicine
yes
Hobby
yes

Area of application

Naturalist
yes
Internal medicine
yes
Dermatology
yes

Miscellaneous

supplier product number
E0460053 (E07MIS0053)
show more...

Product safety

manufacturer: Evident Europe GmbH, Caffamacherreihe 8–10, 20355 Hamburg, DE, https://www.evidentscientific.com/
Product safety

Recommended accessories

Microscopes (1)
Stereo zoom head

Evident Olympus Binocular Head U-CBI30-2-2, for CX41

$ 830.00*
Microscopy accessories > Lenses (12)
Objective

Evident Olympus PLN2X/0.06 Plan Achromatic Objective

$ 920.00*
+ Show more accessories in this category: 11
Microscopy accessories > Cameras (3)
Camera adaptor

Evident Olympus Camera adaptor TV Adapter U-TV0.5XC-3-8, C-Mount Adapter

$ 1,030.00*
+ Show more accessories in this category: 2
Microscopy accessories > Contrast methods (5)
no image

Evident Olympus U-POT Polarisator für DIC-Schieber U-DICRH

$ 385.00*
+ Show more accessories in this category: 4
Microscopy accessories > Miscellaneous (6)
no image

Evident Olympus Olympus CX3-HLDT slide holder

$ 215.00*
+ Show more accessories in this category: 5
Microscopy accessories > Other (3)
no image

Evident Olympus Eyecup, 1 pcs, for CX22, WHB10X

$ 15.90*
+ Show more accessories in this category: 2
Microscopy supplies > Consumables (7)

Bresser Immersion oil, 5ml, refractive index=1.515

$ 10.90*
Baseprice: $ 2,180.00/L
+ Show more accessories in this category: 6
Microscopy supplies > Other (3)

Omegon Experiment Set

$ 20.68*
+ Show more accessories in this category: 2

*All prices include VAT plus shipping costs.

show more...
Evident Olympus Microscope CX43 Standard, trino, infinity, LED, w.o. objectives!
Brightfield (Leukocyte)
Evident Olympus Microscope CX43 Standard, trino, infinity, LED, w.o. objectives!
Brightfield (urinary cast)
Evident Olympus Microscope CX43 Standard, trino, infinity, LED, w.o. objectives!
Phase contrast (Hela cells)
