Product no.: 62783

Montierung EQ-500 X

$ 518.46 Now only:
$ 393.78 incl. VAT plus shipping costs
too expensive?
in stock
ready for shipping in 24 h + lead time

Right of return up to January 31 2025!


Product description

Specifications

Capacity


Designation
EQ-500 X
Max. additional load capacity (kg)
10
Mounting saddle
Vixen-Style
Weight mount head only (kg)
4,2
Counterweight(s) (piece)
2 (@ 2,5 kg)
Diameter of counterweight bar (mm)
20
Polar elevation setting (°)
5 - 60°
Drive type
Worm wheel

Special features


Polar axis scale
yes
Level
yes

Equipment


Tripod
Tripod
Accessory plate
yes
Pole finder
no
Motor-powered
no

Tripod


Max. tripod height (cm)
102
Min. tripod height (cm)
61
Tripod weight (kg)
7
Tripod material
Stahl
Tripod leg diameter (mm)
45

General


Colour
white
Total weight (kg)
17
Series
Pro
Type
Mount
Type of build
Equatorial

Area of application


Useful for photographs
-
Visually useful
yes

Product safety

manufacturer: NIMAX GmbH, Otto-Lilienthal-Str. 9, 86899 Landsberg am Lech, DE, www.nimax.de
Omegon Montierung EQ-500 X
Omegon Montierung EQ-500 X
Omegon Montierung EQ-500 X
Omegon Montierung EQ-500 X
Omegon Montierung EQ-500 X

Customer reviews

Great EQ mount! :)

Review by C. H. on 23.08.2020 02:46:10

( 5 / 5 )

Everything is metal/steel, solid and sturdy. Feels tough and decent quality.
No instructions, no warranty or any notes was included in the package.
But nonetheless, it's easy to figure out and assemble.

ADVICE:
I noticed some of the turning gears, I can feel friction and have spotted metal dust and thread shavings. Clean it up with magnet or vacuum, add some appropriate lubrication. I add lithium grease to the polar align gear threads and weight bar threads.
Before adding the weights, turn all the axis points a 2-3 times fully, to 'break in' and lubricate the gear teeth. This method improved the turning and feels smoother.

This is my first equatorial mount. I was trying to find one good value for it's good weight capabilities.

I received the mount in good time.
I'm pretty pleased with it!
Highly recommend! :)
